型號 |
YGM7826 |
YGM8327 |
YGM9531 |
YGM3220 |
磨輥數量(個) |
3 |
3 |
4 |
4 |
磨輥直徑 |
260 |
270 |
310 |
320 |
磨環內經(mm) |
780 |
830 |
950 |
970 |
主機轉速(r/min) |
160 |
140 |
130 |
130 |
最大進料粒度 |
20 |
20 |
25 |
20-25 |
產量(kg/h) |
25-500 |
30-680 |
150-1000 |
3000-6000 |
主機功率 |
Y225M-8-18.5 |
Y225M-8-22 |
Y225S-4-37 |
Y225S-4-45 |
風機功率 |
Y160L-4-15 |
Y180M-4-18.5 |
Y200L-4-30 |
Y200L-4-37 |
分析機電機型號 |
Y160M-6-7.5 |
Y160M-6-7.5 |
Y160M-6-7.5 |
YCT200-4A-11 |
總功率 |
41 |
48 |
74.5 |
93 |
外形尺寸 |
4.5×4.2×5.1 |
5.3×4.1×5.2 |
7.1×5.9×7.9 |
7.1*6.1*8.2 |
重量(T) |
4.8 |
6 |
11.5 |
13.2 |
成品粒徑 |
100 mesh to 1250 mesh,the finest can reach 2500 mesh |
